PRODUCT DETAIL

Place of Origin::
Shenzhen
Brand Name::
Greetwin
Certification::
CE, RoHS
Model Number::
GW-18C-LB
Minimum Order Quantity::
1 Piece
Price::
US $20.67
Packaging Details::
Neutral Packing, Product Size: 197*152*210mm. Packing Size: 315*210*56mm
Delivery Time::
5-8 work days
Payment Terms::
L/C, T/T, Western Union, MoneyGram
Supply Ability::
2000PCS/Month

Greetwin Economical Network Booster Mobile Signal Repeater 850 Cdma B5 18dBm High Gain Cellular Signal Booster

Parameter:

Frequency Range			Uplink		Downlink
CDMA 850			824-849MHz		869-894MHZ
Max. Gain			55dB ±2dB		60dB±2dB
Max. Output Power			>18dBm±2dB		>18dBm±2dB
Band width			Wide Band
Ripple in Band			≤ 8dB
Noise Figure			≤ 6dB
VSWR			≤ 2.0
Spurious Emission	9KHz~1GHz		≤ -36dBm
	1~12.75GHz		≤ -30dBm
Time Delay			≤ 1.5 μs
MTBF			> 50000 hours
Impedance			50 ohm
Power Supply			AC 90-240V,DC 12V/3A
Power LED			Power indicator
Alarm LED		Red	Strong input signal
		Green	Normal
Mechanical Specification
RF Connector				N-Female
Cooling				Heatsink Convection cooling
Humidity				< 90%
Operating Temperature				-10°C ~ +55°C
Environment Conditions				IP40
Installation Type				Wall Installation
Size				140x100x20mm
Weight				0.5KG
