| Quantity: | |
|---|---|
China
GREETWIN
SGS, ISO9001
GW-JMP12-IED
1pcs
Contact Us
Box with PE Foam
3 Working Days After Received Payment
T/T, L/C, Western Union, MoneyGram
20000pcs per Month
| GW-JMP12-IED-E 12 Bands | GW-JMP12-IED-IED-A 12 Bands | ||||
| 20-100MHz: 80W Remote Control | Omni Antenna | 20-100MHz: 80W Remote Control | Omni Antenna | ||
| 130-200MHz:80W VHF | Omni Antenna | 130-200MHz:80W VHF | Omni Antenna | ||
| 300-500MHz:80W UHF, Remote Control | Omni Antenna | 300-500MHz:80W UHF, Remote Control | Omni Antenna | ||
| 920-960MHz: 100W GSM900 |
Built-in Directional Antennas for these 9 bands | 850-895MHz 100W CDMA |
Built-in Directional Antennas for these 9 bands | ||
| 1800-1920MHz 100 W DCS GSM 1800 | 1800-2000MHz 100 W DCS PCS | ||||
| 2100-2170MHz 100 W 3G UMTS | 2100-2170MHz 100W 3G UMTS | ||||
| 2570-2690MHz:100W 4G LTE High | 2500-2700MHz:100W 4G High | ||||
| 758-825MHz:100W 4G LTE Low | 725-805MHz:100W 4G Low | ||||
| 2400-2500MHz: 100 W WiFi 11.b, g | 2300-2500MHz: 100 W WiFi 11.b, g | ||||
| 3400-3600MHz :80W (or 1170-1300MHz:100W GPS L2 + Glonoass L2 + GPS L5) | 610-650MHz: 80W (or 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5) | ||||
| 1570-1620MH: 100W GPS L1 + Glonass L1 | 1570-1620MH: 100W GPS L1 + Glonass L1 | ||||
| 5.1-5.9GHz: 30W WiFi 11.a (or 80W) | 5.1-5.9GHz: 30W WiFi 11.a (or 80W) | ||||
| Total : 1050W | Total : 1050W | ||||
| 100% Safe VSWR over protection (Isolator) for each modular | |||||
| Power supply: | AC110 or 220-240V /DC 48V | ||||
| Jamming Range | Radius 100~300 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-4912-IED 45kg | ||||
| Dimension: | 626 mm(L)×49.2mm(W)× 350mm(H), Pelican 1620 | ||||
| Working time: | Without the time limit, May continue to work, | ||||
| GW-JMP12-IED-E 12 Bands | GW-JMP12-IED-IED-A 12 Bands | ||||
| 20-100MHz: 80W Remote Control | Omni Antenna | 20-100MHz: 80W Remote Control | Omni Antenna | ||
| 130-200MHz:80W VHF | Omni Antenna | 130-200MHz:80W VHF | Omni Antenna | ||
| 300-500MHz:80W UHF, Remote Control | Omni Antenna | 300-500MHz:80W UHF, Remote Control | Omni Antenna | ||
| 920-960MHz: 100W GSM900 |
Built-in Directional Antennas for these 9 bands | 850-895MHz 100W CDMA |
Built-in Directional Antennas for these 9 bands | ||
| 1800-1920MHz 100 W DCS GSM 1800 | 1800-2000MHz 100 W DCS PCS | ||||
| 2100-2170MHz 100 W 3G UMTS | 2100-2170MHz 100W 3G UMTS | ||||
| 2570-2690MHz:100W 4G LTE High | 2500-2700MHz:100W 4G High | ||||
| 758-825MHz:100W 4G LTE Low | 725-805MHz:100W 4G Low | ||||
| 2400-2500MHz: 100 W WiFi 11.b, g | 2300-2500MHz: 100 W WiFi 11.b, g | ||||
| 3400-3600MHz :80W (or 1170-1300MHz:100W GPS L2 + Glonoass L2 + GPS L5) | 610-650MHz: 80W (or 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5) | ||||
| 1570-1620MH: 100W GPS L1 + Glonass L1 | 1570-1620MH: 100W GPS L1 + Glonass L1 | ||||
| 5.1-5.9GHz: 30W WiFi 11.a (or 80W) | 5.1-5.9GHz: 30W WiFi 11.a (or 80W) | ||||
| Total : 1050W | Total : 1050W | ||||
| 100% Safe VSWR over protection (Isolator) for each modular | |||||
| Power supply: | AC110 or 220-240V /DC 48V | ||||
| Jamming Range | Radius 100~300 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-4912-IED 45kg | ||||
| Dimension: | 626 mm(L)×49.2mm(W)× 350mm(H), Pelican 1620 | ||||
| Working time: | Without the time limit, May continue to work, | ||||
