| Quantity: | |
|---|---|
China
GREETWIN
SGS, ISO9001
GW-JMP540XF
1pcs
Contact Us
Box with PE Foam
3 Working Days After Received Payment
T/T, L/C, Western Union, MoneyGram
20000pcs per Month
| Frequency | PCB-6080 ( 5 Bands) | PCB-6081 ( 6 Bands) |
| 450-470MHz | 120W | 100W (Option) |
| 850-889MHz | 120W | 120W |
| 920-966MHz | 120W | 120W |
| 1805-1920MHz | 100W | 100W |
| 2100-2175MHz | 100W | 100W |
| 130-180MHz | 50W (Option) | 50W |
| 420-480MHz | 50W (Option) | 50W |
| 2.4GHz WiFi | 15W (Option) | 15W |
| GPS L1 or L2 | 15W (Option) | 15W |
| Total output power: | 560 W | 540 W |
| Power supply: | AC adapter (AC220V-DC27V or 24V/ 40-50 Amp) | |
| Jamming Range: | 500-1000 meters@ï¼75dBm | |
| Stand-alone modular design and individual power control. | ||
| Adjustable Output Power each Band/Channel | ||
| Remote Control | ||
| VSWR over protection for each modular. | ||
| Temperature over protection. | ||
| Working status indicator for each band modular. | ||
| Cover network standards: AMPS,N-AMPS, DCS,NMT,TACS,GSM,CDMA,TDMA,IDEN,UMTS | ||
| 450MHz/ | ||
| Designed to cut off down-link only, Therefore it doesn’t have Interference to base station and repeater. | ||
| Dimension:69cm(L)×69cm(W)×39cm(D) | ||
| Weight:65 Kg (approximately) just main unit not included antenna & all accessories | ||
| Operating temperature: -20â ~ +60â | ||
| Humidity: 5% ~ 90% | ||
| Antennas Spec | 450-470Mhz :65° Panel | 10dBi, 600x290x90m, 6.5Kg |
| | 851-960Mhz :65° Panel | 12dBi, 600x290x90m, 6.5Kg |
| 1805-1990Mhz :65° Panel | 15dBi, 700x165x55m, 5.0Kg | |
| | 2000-2200Mhz :65° Panel | 15dBi, 700x165x55m, 5.0Kg |
| | 2400-2500Mhz :65° Panel | 18dBi, 700x165x55m, 5.0Kg |
| Warranty: | 1 year | |
| Frequency | PCB-6080 ( 5 Bands) | PCB-6081 ( 6 Bands) |
| 450-470MHz | 120W | 100W (Option) |
| 850-889MHz | 120W | 120W |
| 920-966MHz | 120W | 120W |
| 1805-1920MHz | 100W | 100W |
| 2100-2175MHz | 100W | 100W |
| 130-180MHz | 50W (Option) | 50W |
| 420-480MHz | 50W (Option) | 50W |
| 2.4GHz WiFi | 15W (Option) | 15W |
| GPS L1 or L2 | 15W (Option) | 15W |
| Total output power: | 560 W | 540 W |
| Power supply: | AC adapter (AC220V-DC27V or 24V/ 40-50 Amp) | |
| Jamming Range: | 500-1000 meters@ï¼75dBm | |
| Stand-alone modular design and individual power control. | ||
| Adjustable Output Power each Band/Channel | ||
| Remote Control | ||
| VSWR over protection for each modular. | ||
| Temperature over protection. | ||
| Working status indicator for each band modular. | ||
| Cover network standards: AMPS,N-AMPS, DCS,NMT,TACS,GSM,CDMA,TDMA,IDEN,UMTS | ||
| 450MHz/ | ||
| Designed to cut off down-link only, Therefore it doesn’t have Interference to base station and repeater. | ||
| Dimension:69cm(L)×69cm(W)×39cm(D) | ||
| Weight:65 Kg (approximately) just main unit not included antenna & all accessories | ||
| Operating temperature: -20â ~ +60â | ||
| Humidity: 5% ~ 90% | ||
| Antennas Spec | 450-470Mhz :65° Panel | 10dBi, 600x290x90m, 6.5Kg |
| | 851-960Mhz :65° Panel | 12dBi, 600x290x90m, 6.5Kg |
| 1805-1990Mhz :65° Panel | 15dBi, 700x165x55m, 5.0Kg | |
| | 2000-2200Mhz :65° Panel | 15dBi, 700x165x55m, 5.0Kg |
| | 2400-2500Mhz :65° Panel | 18dBi, 700x165x55m, 5.0Kg |
| Warranty: | 1 year | |
