| Quantity: | |
|---|---|
China
GREETWIN
SGS, ISO9001
GW-JBP12-IED
1pcs
Contact Us
Box with PE Foam
3 Working Days After Received Payment
T/T, L/C, Western Union, MoneyGram
20000pcs per Month
| GW-JBP12-IED 12 Bands | GW-JBP12-IED 12 Bands | ||||
| 20-100MHz: 50W Remote Control | Omni Antenna | 20-100MHz: 50W Remote Control | Omni Antenna | ||
| 130-200MHz:60W VHF | Omni Antenna | 130-200MHz:60W VHF | Omni Antenna | ||
| 300-500MHz:60W UHF, Remote Control | Omni Antenna | 300-500MHz:60W UHF, Remote Control | Omni Antenna | ||
| 920-960MHz: 60W GSM900 |
Built-in Directional Antennas for these 9 bands | 850-895MHz 60W CDMA |
Built-in Directional Antennas for these 9 bands | ||
| 1800-1920MHz 50 W DCS GSM 1800 | 1800-2000MHz 50 W DCS PCS | ||||
| 2100-2170MHz 50 W 3G UMTS | 2100-2170MHz 50W 3G UMTS | ||||
| 2570-2690MHz:40W 4G LTE High | 2500-2700MHz:40W 4G High | ||||
| 758-825MHz:60W 4G LTE Low+5G LTE | 725-805MHz:60W 4G Low | ||||
| 2400-2500MHz: 40 W WiFi 11.b, g | 2400-2500MHz: 40 W WiFi 11.b, g | ||||
| 3400-3800MHz: 20W 5G LTE (or 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5 | 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5 (or 610-652MHz: 50W) | ||||
| 1570-1620MH: 50W GPS L1 + Glonass L1 | 1570-1620MH: 50W GPS L1 + Glonass L1 | ||||
| 5.1-5.9GHz: 20W WiFi 11.a | 5.1-5.9GHz: 20W WiFi 11.a | ||||
| Total : 600W | Total : 600W | ||||
| Battery | +24V / 50AH LiFePO4 can work 120 Minutes Switching between AC 220/110V and Built-in Battery Option: External Battery B-50AH/DC27V work 3 Hours | ||||
| Power supply: | AC110 or 220-240V /DC 27V | ||||
| Jamming Range | Radius 100~300 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-4912B-IED 51kg | ||||
| Dimension: | 626 mm(L)×49.2mm(W)× 350mm(H), Pelican 1620 | ||||
| Working time: | Without the time limit, May continue to work, | ||||
| GW-JBP12-IED 12 Bands | GW-JBP12-IED 12 Bands | ||||
| 20-100MHz: 50W Remote Control | Omni Antenna | 20-100MHz: 50W Remote Control | Omni Antenna | ||
| 130-200MHz:60W VHF | Omni Antenna | 130-200MHz:60W VHF | Omni Antenna | ||
| 300-500MHz:60W UHF, Remote Control | Omni Antenna | 300-500MHz:60W UHF, Remote Control | Omni Antenna | ||
| 920-960MHz: 60W GSM900 |
Built-in Directional Antennas for these 9 bands | 850-895MHz 60W CDMA |
Built-in Directional Antennas for these 9 bands | ||
| 1800-1920MHz 50 W DCS GSM 1800 | 1800-2000MHz 50 W DCS PCS | ||||
| 2100-2170MHz 50 W 3G UMTS | 2100-2170MHz 50W 3G UMTS | ||||
| 2570-2690MHz:40W 4G LTE High | 2500-2700MHz:40W 4G High | ||||
| 758-825MHz:60W 4G LTE Low+5G LTE | 725-805MHz:60W 4G Low | ||||
| 2400-2500MHz: 40 W WiFi 11.b, g | 2400-2500MHz: 40 W WiFi 11.b, g | ||||
| 3400-3800MHz: 20W 5G LTE (or 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5 | 1170-1300MHz:50W GPS L2 + Glonoass L2 + GPS L5 (or 610-652MHz: 50W) | ||||
| 1570-1620MH: 50W GPS L1 + Glonass L1 | 1570-1620MH: 50W GPS L1 + Glonass L1 | ||||
| 5.1-5.9GHz: 20W WiFi 11.a | 5.1-5.9GHz: 20W WiFi 11.a | ||||
| Total : 600W | Total : 600W | ||||
| Battery | +24V / 50AH LiFePO4 can work 120 Minutes Switching between AC 220/110V and Built-in Battery Option: External Battery B-50AH/DC27V work 3 Hours | ||||
| Power supply: | AC110 or 220-240V /DC 27V | ||||
| Jamming Range | Radius 100~300 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-4912B-IED 51kg | ||||
| Dimension: | 626 mm(L)×49.2mm(W)× 350mm(H), Pelican 1620 | ||||
| Working time: | Without the time limit, May continue to work, | ||||
