| Quantity: | |
|---|---|
China
GREETWIN
SGS, ISO9001
GW-JMP86XF
1pcs
Contact Us
Box with PE Foam
3 Working Days After Received Payment
T/T, L/C, Western Union, MoneyGram
20000pcs per Month
| GW-JMP86XF USA | GW-JMP86XF E4G 4G | GW-JMP86XF AGL
| GW-JMP86XF GL VHF UHF | ||
| 850-895MHz 25W | 920-960MHz: 25W GSM900 | 850-895MHz 25W | 920-960MHz: 25W GSM900 | ||
| 1920-2000MHz 20 W | 1800-1880MHz 20 W PCS GSM 1800 | 1920-2000MHz 20 W | 1800-1880MHz 20 W PCS GSM 1800 | ||
| 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | ||
| 700-800MHz:15W iPhone (AT&T & Verizon) | 2620-2690MHz:20W 4G LTE High | 2400-2500MHz:20W WiFi 11.b,g & Buletooth | 2620-2690MHz20W 4G LTE High | ||
| 2500-2700MHz:20W 4G WiMax Sprint+WiFi | 790-870MHz:20W 4G LTE Low | 173MHz:30W LoJack 173 | 173MHz:30W LoJack 173 | ||
| 2400-2500MHz:20W WiFi 11.b,g & Buletooth | 2400-2500MHz: 20 W WiFi 11.b, g | GPS L1 1575MH: 40W (1520-1670MHz: 40W) | GPS L1 1575MH: 40W (1520-1670MHz: 40W) | ||
| Total : 185W | Total : 205 W | Total : 190 W | Total : 175 W | ||
| Option: 5.8GHz: 2.0W, GPS L2 L3 L4 L5: 15W, VHF 130-180MHz: 20W, 300-400MHz: 20W, UHF 420-480MHz: 20W, 4G 2620-2690MHz: 20W, LoJack 173MHz: 30W | |||||
| Adjustable Output Power each Band/Channel, Max Output Power to 0 (OFF) 100% Safe VSWR over protection (Isolator) for each modular | |||||
| Battery | +24V / 20AH LiFePO4 can work 1 Hours | ||||
| Power supply: | AC110 or 220-240V /DC 27V | ||||
| Jamming Range | Radius 50~150 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-3086B 26kg | ||||
| Dimension: | 500 x 305 x 457 mm (Pelican 1440 Case only ) | ||||
| Working time: | Without the time limit, May continue to work, | ||||
| Antenna | External Omni 750mm long or Directional Patch Panel Antennas | ||||
| Warranty: | 1 year | ||||
| GW-JMP86XF USA | GW-JMP86XF E4G 4G | GW-JMP86XF AGL
| GW-JMP86XF GL VHF UHF | ||
| 850-895MHz 25W | 920-960MHz: 25W GSM900 | 850-895MHz 25W | 920-960MHz: 25W GSM900 | ||
| 1920-2000MHz 20 W | 1800-1880MHz 20 W PCS GSM 1800 | 1920-2000MHz 20 W | 1800-1880MHz 20 W PCS GSM 1800 | ||
| 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | 2100-2170MHz 30 W 3G UMTS | ||
| 700-800MHz:15W iPhone (AT&T & Verizon) | 2620-2690MHz:20W 4G LTE High | 2400-2500MHz:20W WiFi 11.b,g & Buletooth | 2620-2690MHz20W 4G LTE High | ||
| 2500-2700MHz:20W 4G WiMax Sprint+WiFi | 790-870MHz:20W 4G LTE Low | 173MHz:30W LoJack 173 | 173MHz:30W LoJack 173 | ||
| 2400-2500MHz:20W WiFi 11.b,g & Buletooth | 2400-2500MHz: 20 W WiFi 11.b, g | GPS L1 1575MH: 40W (1520-1670MHz: 40W) | GPS L1 1575MH: 40W (1520-1670MHz: 40W) | ||
| Total : 185W | Total : 205 W | Total : 190 W | Total : 175 W | ||
| Option: 5.8GHz: 2.0W, GPS L2 L3 L4 L5: 15W, VHF 130-180MHz: 20W, 300-400MHz: 20W, UHF 420-480MHz: 20W, 4G 2620-2690MHz: 20W, LoJack 173MHz: 30W | |||||
| Adjustable Output Power each Band/Channel, Max Output Power to 0 (OFF) 100% Safe VSWR over protection (Isolator) for each modular | |||||
| Battery | +24V / 20AH LiFePO4 can work 1 Hours | ||||
| Power supply: | AC110 or 220-240V /DC 27V | ||||
| Jamming Range | Radius 50~150 meters (-75dBm@Omnidirectional antennas) | ||||
| Weight | PCB-3086B 26kg | ||||
| Dimension: | 500 x 305 x 457 mm (Pelican 1440 Case only ) | ||||
| Working time: | Without the time limit, May continue to work, | ||||
| Antenna | External Omni 750mm long or Directional Patch Panel Antennas | ||||
| Warranty: | 1 year | ||||
