| Quantity: | |
|---|---|
China
GREETWIN
SGS, ISO9001
GW-JMP86
1pcs
Contact Us
Box with PE Foam
3 Working Days After Received Payment
T/T, L/C, Western Union, MoneyGram
20000pcs per Month
205W 7bands High Power Cell Phone GPS WiFi 2.4G 5.8g Drone Signal Jammer Up To 500m
| GW-JMP86 USA | GW-JMP86 E4G | GW-JMP86 AGL | GW-JMP86 GL | |
| (6 bands) | 4G (6 bands) | (6 bands) | VHF UHF (6 bands) | |
| 850-895MHz 25W | 920-960MHz: 25W | 850-895MHz 25W | 920-960MHz: 25W | |
| GSM900 | GSM900 | |||
| 1920-2000MHz | 1800-1880MHz 20 W PCS GSM 1800 | 1920-2000MHz | 1800-1880MHz 20 W PCS GSM 1800 | |
| 20 W | 20 W | |||
| 2100-2170MHz | 2100-2170MHz 30 W | 2100-2170MHz | 2100-2170MHz 30 W | |
| 30 W 3G UMTS | 3G UMTS | 30 W 3G UMTS | 3G UMTS | |
| 700-800MHz:15W | 2620-2690MHz:20W | 2400-2500MHz:20W | 2620-2690MHz20W | |
| iPhone (AT&T & Verizon) | 4G LTE High | WiFi 11.b,g & Buletooth | 4G LTE High | |
| 2500-2700MHz:20W | 790-870MHz:20W | 173MHz:30W | 173MHz:30W | |
| 4G WiMax Sprint+WiFi | 4G LTE Low | LoJack 173 | LoJack 173 | |
| 2400-2500MHz:20W | 2400-2500MHz: 20 W | GPS L1 1575MH: 40W | GPS L1 1575MH: 40W | |
| WiFi 11.b,g & Buletooth | WiFi 11.b, g | (1520-1670MHz: 40W) | (1520-1670MHz: 40W) | |
| Total : 185W | Total : 205 W | Total : 190 W | Total : 175 W | |
| Option: 5.8GHz: 2.0W, GPS L2 L3 L4 L5: 15W, VHF 130-180MHz: 20W, 300-400MHz: 20W, UHF 420-480MHz: 20W, 4G 2620-2690MHz: 20W, LoJack 173MHz: 30W | ||||
| Adjustable Output Power each Band/Channel, Max Output Power to 0 (OFF) | ||||
| 100% Safe VSWR over protection (Isolator) for each modular | ||||
| Battery | +24V / 20AH LiFePO4 can work 1 Hours | |||
| Power supply: | AC110 or 220-240V /DC 27V | |||
| Jamming Range | Radius 50~150 meters (-75dBm@Omnidirectional antennas) | |||
| Weight | 26kg | |||
| Dimension: | 500 x 305 x 457 mm (Pelican 1440 Case only ) | |||
| Working time: | Without the time limit, May continue to work, | |||
| Antenna | External Omni 750mm long or Directional Patch Panel Antennas | |||
| Warranty: | 1 year | |||
Product Description
High RF power, cover 100% drones UAVs Like Dji Phantom 4, Phantom 3 Professional, Advanced, Standard series, Inspire Series...
Directional Jamming range: 500-800Meters
7Bands in One Device.
More details and specifications of this selectable handheld 2G 3G 4G Lojack jammer are just as follows, if you want to know more just come and get the overall information.
Advantages
Specifications
· Isolating Signal Bandwidth:
- 2.4G: 2400-2500MHz
- 5.8G: 5725-5850MHz
- GPSL1: 1560-1620MHz
- 868-920: 868-916MHz
- GPS L2~L5: 1100~1300MHz
- Wi-Fi5.2G: 5100-5500MHz
- WiFi3.6G: 3500-3600MHz
Total output power:205W
Jamming Range: Up to 500m (depend on cell phone signal Length)
Power Supply: AC110 or 220-240V /DC 27V
Antennas Details: high-tech rubber (7 units)
Dimensions Of Device: 500 x 305 x 457 mm
Weight Of Product: 26.00kg
Accessories
7*Antennas
Car Charger
AC Charger
Remove Control (Option)
