GPSL3L4 2170MHZ Cell Phone Signal Jammer Gps 16 Channels

Quantity:
  • China

  • GREETWIN

  • SGS, ISO9001

  • GW-JN16E

  • 1pcs

  • Contact Us

  • Box with PE Foam

  • 3 Working Days After Received Payment

  • T/T, L/C, Western Union, MoneyGram

  • 20000pcs per Month

16 Channels Antennas Cell Phone Signal Jammer Block Wifi Lojack Gps Mobile 2g 3g 4g 5g







Key technical specifications: N16
Channel Output port Frequency range Average out-putting power
Band 1 VHF&LOJACK 135-175MHz 30±1dBm/ 1±0.2W
Band 2 4G700 or 800 700-805 or 758-821MHz 30±1dBm/ 1±0.2W
Band 3 4G1700or GPSL3L4 1710-1780 or 1370-1390MHz 30±1dBm/ 1±0.2W
Band 4 3G 2110-2170MHZ 30±1dBm/ 1±0.2W
Band 5 WIFI5.2G 5125-5350MHz 30±1dBm/ 1±0.2W
Band 6 GPSL2L5 1170-1280MHz 30±1dBm/ 1±0.2W
Band 7 CDMA&868 850-894MHz 30±1dBm/ 1±0.2W
Band 8 4G2600 or 4G2300 2500-2690 or 2300-2400MHZ 30±1dBm/ 1±0.2W
Band 9 RC315 315MHz 30±1dBm/ 1±0.2W
Band 10 RC433 433MHz 30±1dBm/ 1±0.2W
Band 11 UHF&CDMA450 400-470MHz 30±1dBm/ 1±0.2W
Band 12 GSM&LORA 925-960MHz 30±1dBm/ 1±0.2W
Band 13 GPSL1 1570-1580MHz 30±1dBm/ 1±0.2W
Band 14 WIFI2.4G 2400-2500MHz 30±1dBm/ 1±0.2W
Band 15 DCS/PCS 1805-1880/1920-1990MHz 30±1dBm/ 1±0.2W
Band 16 WIFI5.8G 5725-5850MHz 30±1dBm/ 1±0.2W
Power supply: adapter 50 to 60Hz AC (110-240V AC/12V DC) Car Charger: DC12V IN

Dimensions: (length ,width, height) 190x126x46mm (without antenna)

Length of antenna :166mm Gain:2.0dbi

Packing size: 330*250*80mm Net weight: 1.5kg Gross weight: 2.0kg
Total power: 16W
Shielding radius: (2-25) meters at -75dBm Still depends on the strength signal in given area
Built-in battery:7.4V/12000mAh Continue working: more than 2.5+ hours
Warranty: one year from delivery date



Key technical specifications: N16-EU
Channel Output port Frequency range Average out-putting power
Band 1

VHF&LOJACK



135-175MHz 30±1dBm/ 1±0.2W
Band 2 4G800 758-821MHz 30±1dBm/ 1±0.2W
Band 3 5G1400 1427-1518MHz 30±1dBm/ 1±0.2W
Band 4 3G 2110-2170MHZ 30±1dBm/ 1±0.2W
Band 5 WIFI5.2G 5125-5350MHz 30±1dBm/ 1±0.2W
Band 6 GPSL2L5 1170-1280MHz 30±1dBm/ 1±0.2W
Band 7 GSM 925-960MHz 30±1dBm/ 1±0.2W
Band 8 4G2600 2570-2690MHZ 30±1dBm/ 1±0.2W
Band 9 RC315 315MHz 30±1dBm/ 1±0.2W
Band 10 RC433 433MHz 30±1dBm/ 1±0.2W
Band 11 5G3600 3600-3900MHz 30±1dBm/ 1±0.2W
Band 12 5G3400 3400-3600MHz 30±1dBm/ 1±0.2W
Band 13 GPSL1 1570-1580MHz 30±1dBm/ 1±0.2W
Band 14 WIFI2.4G/4G2300 2345-2500MHz 30±1dBm/ 1±0.2W
Band 15 DCS 1805-1880MHz 30±1dBm/ 1±0.2W
Band 16 WIFI5.8G 5725-5850MHz 30±1dBm/ 1±0.2W
Power supply: adapter 50 to 60Hz AC (110-240V AC/12V DC) Car Charger: DC12V IN

Dimensions: (length ,width, height) 190x126x46mm (without antenna)

Length of antenna :166mm Gain:2.0dbi

Packing size: 330*250*80mm Net weight: 1.5kg Gross weight: 2.0kg
Total power: 16W
Shielding radius: (2-25) meters at -75dBm Still depends on the strength signal in given area
Built-in battery:7.4V/12000mAh Continue working: more than 2.5+ hours
Warranty: one year from delivery date







Key technical specifications: N16-5G US
Channel Output port Frequency range Average out-putting power
Band 1 VHF&LOJACK 135-175MHz 30±1dBm/ 1±0.2W
Band 2 4G700 700-803MHz 30±1dBm/ 1±0.2W
Band 3 5G600 617-685MHz 30±1dBm/ 1±0.2W
Band 4 3G 2110-2170MHZ 30±1dBm/ 1±0.2W
Band 5 WIFI5.2G 5125-5350MHz 30±1dBm/ 1±0.2W
Band 6 4G1700 1710-1780MHz 30±1dBm/ 1±0.2W
Band 7 CDMA 850-894MHz 30±1dBm/ 1±0.2W
Band 8 4G2600 2500-2690MHZ 30±1dBm/ 1±0.2W
Band 9 RC315 315MHz 30±1dBm/ 1±0.2W
Band 10 RC433 433MHz 30±1dBm/ 1±0.2W
Band 11 5G3600 3600-3900MHz 30±1dBm/ 1±0.2W
Band 12 5G3400 3400-3600MHz 30±1dBm/ 1±0.2W
Band 13 GPSL1 1570-1580MHz 30±1dBm/ 1±0.2W
Band 14 WIFI2.4G/4G2300 2345-2500MHz 30±1dBm/ 1±0.2W
Band 15 PCS 1920-1990MHz 30±1dBm/ 1±0.2W
Band 16 WIFI5.8G 5725-5850MHz 30±1dBm/ 1±0.2W
Power supply: adapter 50 to 60Hz AC (110-240V AC/12V DC) Car Charger: DC12V IN

Dimensions: (length ,width, height) 190x126x46mm (without antenna)

Length of antenna :166mm Gain:2.0dbi

Packing size: 330*250*80mm Net weight: 1.5kg Gross weight: 2.0kg
Total power: 16W
Shielding radius: (2-25) meters at -75dBm Still depends on the strength signal in given area
Built-in battery:7.4V/12000mAh Continue working: more than 2.5+ hours
Warranty: one year from delivery date



This is a great 2G, 3G, 4G,5G, and WIFI BLOCKER, Bluetooth jammer, which is also can block all 2.4G frequencies, easily being hidden in your bag, pocket, or purse. It is designed so small and lightweight that you can hide it practically anywhere with no effort. It also looks much alike with common cell phones. Thus even if someone will notice it, he or she will probably think of it as of mobile device of yours.


It is a professional cell phone blocker that needs to be treated accordingly. It gives you real flexibility when it comes to wireless signal protection. This product has switches for every antenna which can be used to select what kind of frequencies you want to prevent from working at every moment of time.



Jammer GW-JN16 is the most powerful portable jamming solution currently available on the market.

It feels like a portable in your hands, however, it definitely behaves like a high power desktop unit. Dimensions are just 87x40x143mm which makes this jammer to look a little bit more massive than iPad mini. The weight is 950g which corresponds to the weight of three and a half iPhone 6. Now just listen to what you have inside this jammer and its possibilities. It's able to jam all GSM frequencies…worldwide! You don't need to mention your country of residence before placing an order with us, this jammer will disable all cell phone frequencies in absolutely all countries where the cellular network exist. It jams 3G (2100 MHz) /4G/5G frequencies as well.

Note: The jamming distances we mentioned on the website are for customer's reference only. The actual jamming distance will be varied depending on the signal strength and the use location and if full charges, etc.

Can customize these frequencies LoJack 173MHz, 433MHz,315MHz, 868MHz, 450MHz, iDEN, CDMA, GSM, GPRS, DCS, PCS, AWS, WCDMA,UMTS,3G,4G,LTE 700, LTE 800, LTE 2300, LTE 2600, 3400,GPS L1,GPS L2, Galileo, Compass, Glonass, WIFI, Bluetooth, Spy camera, WIMAX, UAV, Drone, etc.


Could be used in a car directly, With car charger
It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more
For some locations special purpose such as hospitals, gas stations and more, Please do field test firstly to make sure no interference happened to the normal operation of their equipment and instrument
ODM OEM orders are welcome


Package contents:

(1)Jammer Host x 1,
(2)AC Charger x1,
(3)Omni antenna x16,
(4)Car Charger x1,
(5)External high gain antenna x16(option)
