Product Description
Frequency Range | Uplink | Downlink | |||
GSM 900MHz | 890-915MHz | 935-960MHz | |||
DCS1800MHz | 1710-1785MHz | 1805-1880MHz | |||
WCDMA2100MHz | 1920-1980MHz | 2110-2170MHz | |||
Max. Gain | 60dB ±2dB | 65dB±2dB | |||
Max. Output Power | 17dBm±2dB | 20dBm±2dB | |||
Bandwidth | Wide Band | ||||
Ripple in Band | ≤ 8dB | ||||
Noise Figure | ≤ 6dB | ||||
VSWR | ≤ 2.0 | ||||
Spurious Emission | 9KHz~1GHz | ≤ -36dBm | |||
1~12.75GHz | ≤ -30dBm | ||||
Time Delay | ≤ 1.5 μs | ||||
MTBF | > 50000 hours | ||||
Impedance | 50 ohm | ||||
Power Supply | AC 90-240V,DC 12V/3A | ||||
Power LED | Power indicator | ||||
Alarm LED | Red | Strong input signal | |||
Green | Normal | ||||
Mechanical Specification | |||||
RF Connector | N-Female | ||||
Cooling | Heatsink Convection cooling | ||||
Humidity | < 90% | ||||
Operating Temperature | -10°C ~ +55°C | ||||
Environment Conditions | IP40 | ||||
Installation Type | Wall Installation | ||||
Size | 196*182*22mm | ||||
Weight | < 1.5Kg |
If you have poor cellular signal, a cell phone signal booster is the answer. You are already paying a monthly fee for a service that either doesn't work, or works sporadically. Cell phone boosters provide consistent, reliable cell service for one flat price.
Cell phone boosters (also known as cell phone repeaters) for homes (and similar buildings like cottages, cabins, retreats, etc.) are designed to be permanently installed and fill up the house with strong, quality cell signal.
The following cell signal booster solutions are your best options for better cell signal in your home.
So if you're able to get away with only boosting one carrier, then this is the obvious solution.
And the carrier that the Cel-Fi GO X boosts can easily be switched using an app on your smart phone, so if you change carriers down the line, you don't have to buy a new booster.
Finally, the GO X can be configured with many different types of antennas and cables to meet every situation, so you'll be able to create the perfect solution for your situation. You can even install multiple GO X boosters side by side, one for each carrier, so you get the 100 dB of boosting power AND multi-carrier support.
FAQ
Q1.Payment Method
T/T, Western Union, Paypal, and Credit Card are available,
and we suggest paying by Alibaba Trade Assurance, the most favor, and security method.
*Other methods please Contact us with more details.
Q2.Delivery Date&Lead Time
Quantity | Lead time | Delivery to American/Middle East/Asia/Europe |
<50 pcs | 7 business days | 3-7 business days by DHL 5-7 business days by FedEx/UPS |
50-200 pcs | 7-10 business days | |
>200 pcs | 15-24 business days |
*Click it to get the sample.
Q3. Can I customize frequencies?
Yes, we can customize 2G/3G/4G/CDMA/GSM/DCS/AWS/PCS/WCDMA/LTE,etc.
Q4. What should I do if I don't know about frequency in my country?
Please feel free to Contact us with your inquiry, we will find the frequency you need and address your problems.
Other Signal Repeater
More signal repeater please CLICK it!
