| Quantity: | |
|---|---|
GW-DM8
GREETWIN
To Be Negotiated
5-7 Day
2000PCS/Month
China
GREETWIN
GW-DM8
1 PC
Designed specifically for dynamic outdoor environments, this vehicle mounted drone jammer targets security professionals requiring reliable mobile drone interference solutions. It is an ideal choice for convoy protection, VIP transport security, and emergency response units seeking to neutralize unauthorized drone threats during movement. The integrated anti drone jamming system operates to disrupt communication and control signals, ensuring drones are forced to land or return safely. Users benefit from a device configured for easy rooftop mounting on vehicles, providing a seamless jamming shield around critical assets while on the move.
This anti drone jamming system features coverage across eight essential frequency bands from 400 to 5900 MHz, delivering 400W total output power. These specifications enable the device to block a broad range of drone communication protocols, including those used by most commercial and tactical UAVs. Its omni-directional antenna design grants 360° vertical and 65° horizontal coverage, achieving an effective jamming radius of up to 2 km. Additional technical benefits include rugged construction for extreme temperature operation, DC 24-29V power input compatibility, and a lightweight form factor optimized for vehicle mounting, making it a highly capable fpv jammer in complex operational conditions.
The drone jammer vehicle provides essential anti-UAV capability across various sectors including military patrols, airport security, industrial fleet protection, and public safety event management. Its mobile deployment is critical in environments where fixed jamming solutions are impractical. By integrating this system, security teams expand their protective perimeter dynamically, mitigating risks from drone reconnaissance, smuggling attempts, or hostile surveillance. The device’s adaptability to diverse operational requirements and environments ensures continuous compliance with safety protocols while enhancing situational awareness and control over aerial vulnerabilities.
The vehicle mounted drone jammer incorporates a compact and aerodynamic structure optimized for rooftop installation on multiple vehicle platforms without compromising mobility or stability. Its modular architecture supports quick integration with existing vehicle systems and power supplies, including external batteries and AC power charging. The anti drone jamming system utilizes omni-directional antennas engineered for maximum coverage with minimal physical intrusion, ensuring sustained operation in harsh environments. The design emphasizes durability, meeting standards for temperature extremes and mechanical vibrations, which is essential for continuous outdoor deployment in various climate conditions.
Performance-wise, this fpv jammer provides reliable jamming with a high power output, guaranteeing effective disruption of drone command and control signals at distances reaching 2 km. User interaction simplifies through an accessible control panel, enabling easy configuration and immediate response in critical scenarios. The lightweight design facilitates installation and reduces the impact on vehicle dynamics. End users benefit from extended battery operation time supporting missions lasting up to 1.5 hours without external power, enhancing operational flexibility. This drone jammer vehicle consequently delivers superior protection combined with intuitive usability and logistical convenience for professional security operators.
Equipment Purpose and Usage Scenario
1. Aiming at the remote control and image transmission signals of various drones or FPV. Force the drone to return or land.
2. Installed on the roof of various vehicles to protect moving vehicles
| No. | Item | Remarks |
| Model | DMZ8 | |
| Working Frequency | 400-500/500-600/600-700/700-840/840-1000 1000-1300/2400-2500/5700-5900MHz | Support Customized |
| Output Power | 400W in total | |
| Power consumption | About 800W | |
| Antenna Gain | 3-8dBi | |
| Antenna working angle | Omni 360°vertical; 65°horizontal | |
| Jamming distance | 300-2000m(Depends on jamming ratio/RC power.etc) | |
| Power supply | DC 24-29V External battery, battery charged by AC220V | |
| Battery | 1000WH battery,1-1.5H continuous working | |
| Control method | Control panel | |
| Dimension | Φ60cm*35cm | |
| Weight | 20KG | |
| Working temperature | -40-65ºC |
FAQ
How do I install the 8 Band 400W Vehicle Drone Jammer on a vehicle?
We designed the vehicle mounted drone jammer specifically for easy mounting on roofs. Its compact size and lightweight structure (20 kg, 60 cm diameter) ensure simple installation. We provide guidance to help you securely attach and operate the device using the built-in control panel for hassle-free mobile protection.
Can you customize the frequency bands and power output of this anti drone jamming system?
Yes, we offer customization for the anti drone jamming system's frequency bands and output power to suit your specific operational requirements. Our team works closely with you to tailor the jammer’s performance across the 400 MHz to 5900 MHz range, ensuring maximum compatibility with your drone defense scenarios.
What is the expected battery life of the UAV jammer when used in the field?
Our UAV jammer includes a 1000WH internal battery capable of delivering 1 to 1.5 hours of continuous operation in normal conditions. For longer missions, it supports external battery packs or AC charging to maintain uninterrupted jamming capacity during mobile deployments.
How long does delivery usually take for orders of the drone jammer vehicle system?
Delivery times for our drone jammer vehicle generally range between 5 to 7 days, depending on your location and order specifics. We strive to ensure prompt shipment and clear communication throughout the process so you can deploy your security solution without unnecessary delays.
